IVPTZHDUSB-BEACON (#VPTEZ-03)Compass Camera, Jabra Speak 510, USB Dongle


Our award winning camera, The Compass, pairs up perfectly with the Jabra Speak 510. HD over USB 2.0,Preset camera positions, 1080P resolution at 30 fps, IR, RS232, and UVC camera control, On screen PC camera control application, Attractive, discrete, metal framed design, Bluetooth audio transmission for a clean workspace, Wideband audio for exceptional sound quality, Omni-directional microphone.


  • Compass VPTZH-02 Specifications
    • Focus range/depth of field: f4.9 – 49mm/60cm-infinity
    • Optical distortion: 1.2% -+0.8%
    • Dynamic range: 65db
    • SNR: 50db above
    • FOV: Diagonal 66.6-7.2, Horizontal 53.2-5.3, Vertical 39.8-4.2
    • Sensor size: 1/2.7”
    • Standard Center Tripod mount: ¼”/20 thread
    • MJPEG Format with resolution at 640×480, 1280×720, and 1920×1080 all at 30fps.
    • USB2.0 output
    • RS232 control, compatible with all major control systems
    • UVC Control over USB, software for Near End Camera Control included (download)
    • Dual IR receiver on front
    • Belt Drive Stepper motors with variable speed
    • 9-12V DC input at 1A
    • W 4 5/8” (117.5mm) , D 4 3/8” (111.2mm) , H 5”(127mm)
    • Weight: 1lb 3.2 0z , (.548 Kg)
  • Jabra speak 510 specifications
    • Weight: 195 g
    • Dimensions: D 120 mm x H 33 mm
    • Microphones: Omni-directional
    • Speaker: Dynamic, 50 mm
    • Bluetooth range: Up to 100 m (300 ft), Class 1- Up to 10 m (30 ft), Class 2
    • Bluetooth version 3.0
    • Paired devices Up to 8 trusted devices
    • Supported Bluetooth profiles: A2DP (v 1.2), Hands Free Profile (v1.6), Headset profile
    • Talk time: Up to 15 hours
    • Operating temperature: 5°C to 40°C (41°F to 104°F)
    • Storage temperature: -5°C to 45°C (23°F to 113°F)
